The Superfine Tyre Rubber Grinder can fully meet the needs of customers. Different tire rubber sizes are obtained from the Superfine Tyre Rubber Powder Grinder like 30, 40, 60, 80, 100, 120 mesh.
Simple operation, high output, low energy consumption, and room temperature processing are the characteristics of this machine. It can also save effectively production and maintenance costs and maximize customers benefits.
The adopted double-roller structure can effectively reduce the working temperature, significantly reduce the carbonization rate of fine rubber powder in high-temperature, and improve the quality of the product.
The electrical control adopts PLC and converter flexible control technology, which is more energy-efficient. According to the different needs of customers, variety machines have been developed.
Superfine Tyre Rubber Powder Grinder is used to grind 18-24 mesh powder from 40-80 mesh fine powder,less powder is carbonized.Fine powder is applied to make waterproof membrane,reclaimed rubber and other rubber products.The capacity can reach 6-10 times compared with traditional grinder.
Technical Data
|
Model |
XKM450 |
XKM550 |
|
Roller Diameter(mm) |
Φ450 |
Φ550 |
|
Roller Working Length(mm) |
800 |
1000 |
|
Bearing Type |
Rolling Bearing |
Rolling Bearing |
|
Power(kw) |
90 |
105 |
|
Weight (kg) |
11000 |
17000 |
|
Dimension(mm) |
4520×2110×1450 |
5120×2210×1550 |
|
Production(kg/h) |
200-800 |
400-1200 |
Machine feature:
1.It is composed of base,frame,front and rear roller,universal coupling,TH reducer,roller gap adjusting device,cooling device and eletric control system.
2.The two rollers rotate with different speeds drove from double motors and reducers.
3.The two rollers are made of alloy chilled cast iron with wear-resistant hard surface.
4.It is equipped with PLC frequency control or general electric cabinet control.
Quantity Assembly Site
Input material:rubber powder 10-20mesh.
Final output:rubber powder 40-100mesh.
Less fine rubber powder is carbonized.
The whole production line is PLC fully automatic operation.
The capacity is up to 500-800kg/hour.
This fine rubber powder grinding machine is latest and technical designed machine for tire recycling industry.
8sets Super Fine Rubber Powder Grinders installed in China
Super Fine Rubber Powder Grinders installed Overseas
