Equipment Introduction:
The tire sidewall cutter is used to separate the sidewall from the tread, facilitating subsequent processing. It is one of the three essential pieces of tire pre-processing equipment-alongside the tire strip cutter and the tire block cutter-and serves as the initial step in the tire processing workflow.
Scope of application:
Various types of waste tires: steel-belted tires, nylon tires, radial tires, and tires under 1,200 mm in size.
Equipment Advantages:
1. The cutting tools are made of cemented carbide and can be resharpened for repeated use;
2. The equipment features a sound design, stable performance, and robust durability; it is easy to operate and maintain, and is pollution-free;
3. The company manufactures ring-cutting machines in various specifications to meet the diverse production needs of customers;
4. Customization is supported; machines can be manufactured according to specific customer requirements.
Operating Instructions:
The tire sidewall cutting machine is used to cut off the tire sidewall to facilitate subsequent processing steps. Place the tire on the turntable and use the locking linkage mechanism to securely clamp the inner rim of the tire. Start the machine, grasp the handle to push the swivel arm, and position the blade near the tire crown (ensure the upper limit screw on the vertical column is properly adjusted). Slowly lower the blade, cutting gradually until the sidewall is completely severed. Finally, turn off the power and remove the tire to complete the operation.
Equipment Specifications:
| MODEL | QKF850 | QKF1150 | QKF1500 |
| motor power(kw) | 2.2 | 2.2 | 4 |
| processing range(mm) | 750-1200 | 750-1200 | 1200-1500 |
| capacity(kg/h) | 2000 | 2000 | 2000 |
| weight(kg) | 500 | 550 | 750 |
| size(mm) | 1300*900*1480 | 1520*1150*1480 | 2020*1500*1920 |
Auxiliary equipment for the tire sidewall cutter:
1. The tire sidewall cutter can be used in conjunction with a tire strip cutter and a tire block cutter to break down tires into rubber blocks.
2. Tires that have had their sidewalls removed by the cutter can also be processed directly into tire blocks using a tire shredder.
3. It can be combined with a rubber granulator to form a rubber granule production line.
4. It can be integrated with rubber crackers, screening machines, conveyors, magnetic separators, and other equipment to form a tire rubber powder production line.
